Key Features
● Precision linear slide rail guidance, high straightness and flatness
● Grating closed-loop feedback, micron-level positioning accuracy
● High-reliability drive mechanism, supports heavy loads
● Wedge-shaped lifting internal structure, low overall height, smooth operation
● Screw self-locking plus motor power-off braking function, safe and reliable, long service life
| Stroke | 20mm |
| Repeatability | ±1μm |
| Absolute positioning accuracy | ±3μm |
| Resolution | 0.1μm |
| Maximum speed | 10mm/s |
| Maximum acceleration (unloaded) | 200mm/s² |
| Maximum load | 60kg |
| Load mounting plate dimensions | 300mm*300mm |
