Key Features
● Small volume, high thrust density
● High acceleration/deceleration, heavy load capacity
● Low heat generation, low energy consumption, high stability
● Fast response, high system dynamic performance
● No wear or maintenance-free, unlimited travel
● Modular architecture, support for non-standard customization
| Rated performance | AXTB-9N | AXTB-15N |
| Continuous current | 4.7Arms | 7.6Arms |
| Peak current | 13.8Arms | 22.3Arms |
| Continuous thrust | 315N | 525N |
| Peak thrust | 675N | 1125N |
| Maximum coil temperature | 120℃ | 120℃ |
| Maximum continuous thermal power | 225W | 375W |
| Electrical specifications | AXTB-9N | AXTB-15N |
| Single-phase resistance | 2.61Ω | 1.7Ω |
| Single-phase inductance | 19.6mH | 12.8mH |
| Motor constant | 23.8N/sqrt(W) | 30.8N/sqrt(W) |
| Back EMF constant | 54V/(m/s) | 54V/(m/s) |
| Thrust constant | 67N/Arms | 67N/Arms |
| Electrical time constant | 7.5ms | 7.5ms |
| Mechanical specifications | AXTB-9N | AXTB-15N |
| Mover length | 176mm | 272mm |
| Mover mass | 2.3kg | 3.7kg |
| Stator mass | 3.8kg/m | 3.8kg/m |
| Pole pitch (N-N) | 24mm | 24mm |
| Magnetic attraction force | 1325N | 2075N |
