Key Features
● Repeat positioning accuracy ±0.3μm
● Speed stability ±1%@300mm/s
● High dynamic response characteristics
● Low static jitter
● Fast tuning
● Support for non-standard customization
Advantage
High precision stability
High rigidity granite base, combined with precision ball guides and high-resolution grating, ensures long-term stability and reliability of all accuracies.
High dynamic response and fast tuning
Excellent speed stability and fast in-position tuning, significantly improving production quality and efficiency.
Comprehensive and professional customization capability
Provides full professional customization services for optics, mechanics, electronics, and control, helping customers accelerate product development.
| Effective stroke | X-axis: 300mm Y-axis: 300mm |
| Maximum speed | X-axis: 1000mm/s Y-axis: 1000mm/s |
| Speed stability | X-axis: ±1‰ @ 300mm/s Y-axis: ±1‰ @ 300mm/s |
| Maximum acceleration | X-axis: 1G Y-axis: 1G |
| Repeatability | X-axis: ±0.3μm Y-axis: ±0.3μm |
| Absolute positioning accuracy | X-axis: ±0.5μm Y-axis: ±0.5μm |
| Settling time | X-axis: 20ms @ ±1μm / 0.6G Y-axis: 50ms @ ±1μm / 0.6G |
| Straightness | X-axis: ±1.5μm Y-axis: ±1.5μm |
| Flatness of travel | X-axis: ±3μm Y-axis: ±3μm |
| XY orthogonality | ±3μm |
| Maximum load | 10 kg |
| Grating scale resolution | 0.1μm |
